PIR Sensor BLE 5.0
Template

PIR sensor BLE flow

Flow setup

  1. Start by pulling your beacon into the flow.
  2. Drag to Get variable value from the Dashboard menu.
  3. Drag a Set variable value from the Dashboard menu.
  4. Drag an And gate from the Logic menu.
  5. Drag a Toggle in from the Logic menu
  6. Connect from beacon: Action to Input 2 in Andgate
  7. Also, in the last two Set variable values, create one called Connected and Disconnected.
  8. Drag a line from switched on and switched off to a toggle where switched on goes to On and switched off goes to Off.
  9. Drag a Send SMS in from Notification and connect from And gate output to Send on Send SMS. Fill in your details and what you want the SMS to say.



Dashboard

  1. Tap Menu: Dashboard in the top menu.
  2. Tap into an existing dashboard or create a new one.
  3. Press Edit on the right side and select a: Button and a Value.
  4. Press the small nut on the Button and give it a title e.g. Alarm mode, connect the Variable value armed and disarmed to two buttons with different colours.
  5. Press the nut for value and give it a title such as Status and connect the Variable value to the one called Magnetic switch.
  6. Finish by pressing save on the right side.



Mobile viewing

  1. Tap share on the right side.
  2. Switch Allow public access on.
  3. With that url page, you can access your dashboard on your phone as an app.



Please note! This flow is just an example, your flow can be built according to your needs, this flow is just for inspiration.
